OX Differential Lockers Description
High-Tech aerospace engineering with no castings or stamped steel components. The OX Locker uses a single air-craft quality cable to engage from an open differential to a fully locked unit with a shift of a lever. Super high quality material built for a maximum durability. Less is more, no air lines to leak, no wires to short out.
The new OX Locker™ (Patent Pending) works off the simple mechanism of push/pull. It takes no electricity, no air, and no hassles! The best part is that it locks and unlocks for your driving needs. Unlock for highway driving and tight turns off road. Lock for tough terrain and rock crawling.
OX Locker® Features
Precision Machined Cover
Extra thick billet or forged differential cover. Built to withstand the rigors of offroad. Maintains a stable platform for proper shift fork action. Machined frontal ramp deflects rocks and minimizes damage. No need for extra differential skid plates.
Sure Shifting Engagement
OX Locker engagement is provided by using our super durable manual shifter assembly. Built using billet machined aluminum and steel components. Easy and sure shift action leaves no doubt when you are locked up. This will feed through our custom designed aerospace quality cable assembly. All this adds up to reliability, no leaks, no shorts.
Four Pin Internal Design
Utilizes the proven four spider gear internals. Unique four pin design provides the most strength available of any locker available. This is coupled with an outer case made from 8620 gear steel forged and heat treated to make the OX case virtually indestructible. This design will also be found on the "c-clip" Dana 35 unit, making it the only four pin Dana 35 made!
Extreme Grip Lock Ring
Recently improved to feature a "back cut" gear tooth design. Taken from Porsche racing technology, this lock ring design was a proven solution to high load manual transmission issues. This shift ring is made to find engagement and hold on until you tell it to let go. Case hardened and through hardened to match the quality of the rest of the locker.
Ox Locker® Applications
Dana 30 3.73 and up, 27 spline OXD30C373H-27
Dana 30 3.73 and up, 30 spline OXD30C373H-30
Dana 35 3.55 and up, 27 spline OXD35C355H-27
Dana 35 3.55 and up, 30 spline OXD35C355H-30
Dana 44 3.73 and dn,30 spline OXD44C373D-30
Dana 44 3.92 and up, 30 spline OXD44C392H-30
Dana 44 3.92 and up, 33 spline OXD44C392H-33
Dana 44 JK, Non Rubicon, 30 spline OXD44JK-30
Dana 60 4.10 and dn, 35 spline OXD60C354H-35
Dana 60 4.10 and dn, 30 spline OXD60C354H-30
Dana 60 4.56 and up, 35 spline OXD60C456H-35
Dana 60 4.56 and up, 30 spline OXD60C456H-30
Ford 8.8 2.73 and up, 31 spline OXF88C273H-31
AMC 20 3.08 and up, 29 spline OXA20C308H-29
